| Contact rows | 5 |
|---|
| Contact spacing (termination side) | 2.54 mm |
|---|
| Contact spacing (mating side) | 2.54 mm |
|---|
| Rated current | 1 A |
|---|
| Rated current | Rated current measured at 20 °C, see derating curve for details |
|---|
| Clearance distance | 1 mm between 2 rows (a, b, c) |
|---|
| 1.2 mm between 2 rows (z, d) |
| 1 mm between 2 contacts in a row (a, b, c) |
| 1 mm between 2 contacts in a row (z, d) |
| Creepage distance | 1 mm between 2 rows (a, b, c) |
|---|
| 1.2 mm between 2 rows (z, d) |
| 1 mm between 2 contacts in a row (a, b, c) |
| 1 mm between 2 contacts in a row (z, d) |
| Insulation resistance | >1010 Ω |
|---|
| Contact resistance | ≤20 mΩ for rows a, b, c |
|---|
| ≤30 mΩ for rows z, d |
| Limiting temperature | -40 ... +105 °C upper limiting temperature limited by the pcb |
|---|
| Insertion force | ≤ 160 N |
|---|
| Withdrawal force | ≤ 120 N |
|---|
| Performance level | 1 |
|---|
| acc. to IEC 61076-4-113 |
| Mating cycles | ≥ 500 |
|---|
| Test voltage Ur.m.s. | 1 kV |
|---|
| Isolation group | IIIa (175 ≤ CTI < 400) |
|---|
| PCB thickness | ≥1.6 mm |
|---|
| Hot plugging | No |
|---|
