M12 Power S-cod 3+PE an/- m/- 0° scr

Article No.: 97 00 000 5664

New

Image is for illustration purposes only. Please refer to product description.

New

Cable connector

Article No.: 97 00 000 5664

to see prices and availability.

to see prices and availability.

Cable connector

Angled, Overmoulded

Male

S-coding

Crimp termination

Polyamide (PA)

Contacts: 3

Conductor cross-section: 1.5 mm²

Rated current: ‌12 A

Polyamide (PA), Zinc die-cast

Screw locking

Degree of protection: IP65 / IP67 mated condition

Identification

Version

Technical characteristics

Conductor cross-section (mm²)	1.5 mm²
Conductor cross-section (AWG)	AWG 16
Wire outer diameter	‌ 7.6 mm
Rated voltage	‌ 630 V AC
Rated current	‌ 12 A
Rated impulse voltage	10 kV
Pollution degree	3
Contact resistance	≤ 0.3 mΩ
Limiting temperature	-40 ... +80 °C unmoved
	-30 ... +80 °C moved
	-5 ... +60 °C drag chain
Tightening torque	‌0.6 Nm
Mating cycles	≥ 100
Degree of protection acc. to IEC 60529	IP65 / IP67 mated condition
Overvoltage category	III

Material properties

China RoHS	e
RoHS	compliant
REACH SVHC substances	Yes
REACH Annex XVII substances	Not contained
REACH ANNEX XIV substances	Not contained
ELV status	compliant
California Proposition 65 substances	Yes
REACH SVHC substances	Decabromdiphenylethan (DBDPE)
California Proposition 65 substances	Lead
PFAS	No
Material (insert)	Polyamide (PA)
Material (hood/housing)	Polyamide (PA)
Material (hood/housing)	Zinc die-cast

Specifications and approvals

Commercial data

European customs tariff number	85444290
Packaging size	1
Net weight	0.017 kg
Country of origin	Romania
eCl@ss	27440116 Circular connector (for field assembly)
