M8 A-coded CA 3p st/- m/- 5m shld PVC

Article No.: 21 34 730 0335 050

Image is for illustration purposes only. Please refer to product description.

Cable assemblies

Article No.: 21 34 730 0335 050

to see prices and availability.

to see prices and availability.

Cable assemblies

Pre-assembled on one side

Copper cable (round)

Cable length: 5 m

Parts list specification

Type of cable	(3x0,25mm²) PVC Show details
Connector 1	M8 A 3pole male straight shld overmolded Show details

Identification

Version

Technical characteristics

Limiting temperature	-20 ... +80 °C

Material properties

Material (cable)	PVC
Colour (cable)	Grey
RoHS	compliant with exemption
RoHS exemptions	6(c): Copper alloy containing up to 4 % lead by weight
ELV status	compliant with exemption
China RoHS	50
REACH Annex XVII substances	Not contained
REACH ANNEX XIV substances	Not contained
REACH SVHC substances	Yes
REACH SVHC substances	Lead
ECHA SCIP number	0d7d3693-d625-47ab-934a-d241bf72c86e
California Proposition 65 substances	Yes
California Proposition 65 substances	Lead

Commercial data

Packaging size	10
Net weight	190 g
Country of origin	Czechia
European customs tariff number	85444290
GTIN	5713140241558
eCl@ss	27060311 Assembled sensor actuator-line
ETIM	EC001855
UNSPSC 24.0	26121604
