SEK-18 SV FE TYPA ANS 14P PLS4

Article No.: 09 18 514 5804

Configurable

Image is for illustration purposes only. Please refer to product description.

Configurable

Female connector

Article No.: 09 18 514 5804

to see prices and availability.

to see prices and availability.

Female connector

Closed end cover

IDC insulation displacement termination

Rated current: ‌2.5 A

Thermoplastic resin (PBT)

Grey

Contacts: 14

Performance level: NM 30 (S4)

Copper alloy

Noble metal over Ni Mating side, Sn over Ni Termination side

Identification

Version

Termination method	IDC insulation displacement termination
Connection type	PCB to cable
Number of contacts	14
Details	for IDC flat cable 1.27 mm (0.050ʺ) pitch
Details	AWG 28/7 - AWG 26/7

Technical characteristics

Contact rows	2
Contact spacing (termination side)	2.54 mm
Contact spacing (mating side)	1.27 mm
Rated current	‌ 2.5 A
Insulation resistance	>10⁹ Ω
Contact resistance	≤ 20 mΩ
Limiting temperature	-55 ... +125 °C
Insertion force	≤ 28 N
Withdrawal force	≤ 28 N
Performance level	NM 30 (S4)
Mating cycles	≥ 250
Test voltage Ur.m.s.	1 kV
Isolation group	IIIa (175 ≤ CTI < 400)

Material properties

Material (insert)	Thermoplastic resin (PBT)
Colour (insert)	Grey
Material (contacts)	Copper alloy
Surface (contacts)	Noble metal over Ni Mating side
Surface (contacts)	Sn over Ni Termination side
Layer thickness	≥ 0.76 µm
Layer thickness	≥ 30 µinch
Material flammability class acc. to UL 94	V-0
RoHS	compliant
ELV status	compliant
China RoHS	e
REACH Annex XVII substances	Not contained
REACH ANNEX XIV substances	Not contained
REACH SVHC substances	Not contained
California Proposition 65 substances	Yes
California Proposition 65 substances	Nickel
Fire protection on railway vehicles	EN 45545-2 (2020-08)
Requirement set with Hazard Levels	R26

Specifications and approvals

Commercial data

Packaging size	100
Net weight	2.49 g
Country of origin	Romania
European customs tariff number	85366990
GTIN	5713140210769
eCl@ss	27460202 PCB connector (conductor connection)
ETIM	EC002637
UNSPSC 24.0	39121415
