Han® ORV3 Power 6+PE Crimp, Left/Right

Article No.: 09 93 006 0330

New

Image is for illustration purposes only. Please refer to product description.

New

Connector sets

Article No.: 09 93 006 0330

to see prices and availability.

to see prices and availability.

Connector sets

Male

Rated current: ‌32 A

Contacts: 7

Housing

Left/right hand version

Material: Polyamide (PA)

Degree of protection: IP20

Identification

Category	Connector sets
Series of hoods/housings	Han^® ORV3 power
Type of hood/housing	Housing
Description of hood/housing	Left/right hand version
Features	For Data Center Applications
	First mate - last break
	PE Contact

Version

Technical characteristics

Rated current	‌ 32 A
Rated current	32 A @ 10 mm²
Rated current	20 A @ 10 mm²
Rated voltage	‌ 277 V AC
Rated voltage	‌ 480 V AC
Rated impulse voltage	2.5 kV
Pollution degree	2
Overvoltage category	II
Insulation resistance	> 5 x 10⁸ Ω
Limiting temperature	-40 ... +90 °C
Insertion force	≈ 110 N
Withdrawal force	≈ 110 N
Mating cycles	≥ 100
Degree of protection acc. to IEC 60529	IP20
Vibration resistance	II acc. EiA 364-28
Vibration resistance	VII acc. EiA 364-28F
Shock resistance	A acc. EiA 364-27F

Material properties

Material (hood/housing)	Polyamide (PA)
Material flammability class acc. to UL 94	V-0
RoHS	compliant
ELV status	compliant
China RoHS	e
REACH Annex XVII substances	Not contained
REACH ANNEX XIV substances	Not contained
REACH SVHC substances	Not contained
California Proposition 65 substances	Not contained
Fire protection on railway vehicles	EN 45545-2 (2020-08)
Requirement set with Hazard Levels	R22 (HL 1-3)
Requirement set with Hazard Levels	R23 (HL 1-3)

Specifications and approvals

Specifications	OCP V1.0
Approvals	CE

Commercial data

Packaging size	10
Net weight	24 g
Country of origin	USA
European customs tariff number	85389099
GTIN	5713140445604
eCl@ss	27440114 Rectangular connector (for field assembly)
ETIM	EC002636
UNSPSC 24.0	39121408
