| Contact spacing (termination side) | 1.27 mm |
|---|
| 2.54 mm |
| Contact spacing (mating side) | 1.27 mm |
|---|
| 2.54 mm |
| Stacking height | 3.25 mm |
|---|
| Rated voltage | 50 V AC |
|---|
| 120 V DC |
| Rated voltage | acc. to IEC 60664-1 |
|---|
| Rated impulse voltage | 1.5 kV |
|---|
| Pollution degree | 2 |
|---|
| Clearance distance | ≥0.4 mm Signal contacts |
|---|
| ≥1.74 mm Power contacts |
| ≥1.11 mm Signal to power contacts |
| Creepage distance | ≥0.4 mm PCB: Signal contacts |
|---|
| ≥1.74 mm PCB: Power contacts |
| ≥1.11 mm PCB: Signal to power contacts |
| ≥0.4 mm Connector: Signal contacts |
| ≥1.89 mm Connector: Power contacts |
| ≥1.94 mm Connector: Signal to power contacts |
| Insulation resistance | >1010 Ω |
|---|
| Contact resistance | ≤ 25 mΩ |
|---|
| Limiting temperature | -55 ... +125 °C |
|---|
| Performance level | 1 |
|---|
| Mating cycles | ≥ 500 |
|---|
| Test voltage Ur.m.s. | 0.5 kV Signal |
|---|
| 1.39 kV Signal / Power |
| 1.39 kV Power / Power |
| Isolation group | IIIa (175 ≤ CTI < 400) |
|---|
| Moisture Sensitivity Level (MSL) | 1 acc. to ECA/IPC/JEDEC J-STD-020D |
|---|
| Process Sensitivity Level (PSL) | R0 acc. to ECA/IPC/JEDEC J-STD-020D |
|---|
| Coplanarity of contacts | 0.12 mm |
|---|
