| Conductor cross-section | 0.12 ... 0.32 mm² Stranded |
|---|
| 0.12 ... 0.32 mm² Solid |
| Conductor cross-section [AWG] | AWG 26/7 ... AWG 22/7 Stranded |
|---|
| AWG 24/1 ... AWG 22/1 Solid |
| Wire outer diameter | 0.8 ... 1.6 mm |
|---|
| Transmission characteristics | Cat. 6A Class EA up to 500 MHz |
|---|
| Data rate | 10 Mbit/s |
|---|
| 100 Mbit/s |
| 1 Gbit/s |
| 2.5 Gbit/s |
| 5 Gbit/s |
| 10 Gbit/s |
| Limiting temperature | -40 ... +85 °C |
|---|
| Mating cycles | ≥ 750 |
|---|
| Degree of protection acc. to IEC 60529 | IP65 |
|---|
| IP67 |
| Cable diameter | 6.5 ... 9.5 mm |
|---|
| Vibration resistance | 10-500 Hz, 0.35 mm / 50 m/s², 2h/axis |
|---|
| 5.72 m/s² acc. to IEC 61373 Category 1 Class B |
| Shock resistance | 50 g / 30 ms, 3 shocks / axis and direction acc. to IEC 61373 Category 1 Class B |
|---|
